Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.079 |
| A dimension MM | 27.400 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.250 |
| Compatible hose ID MM | 6.400 |
| Construction Style | Crimp |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.000 |
| Hex size 1 MM | 0.000 |
| Hex size 2 IN | 0.000 |
| Hose size | -4 |
| Inside diameter IN | 0.440 |
| Inside diameter MM | 11.200 |
| Product height in | 0.830 |
| Product height mm | 21.082 |
| Product length in | 1.080 |
| Product length mm | 27.432 |
| Product material | Carbon steel |
| Product width in | 0.830 |
| Product width mm | 21.082 mm |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
