Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.910 |
| A dimension MM | 74.000 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.500 |
| Compatible hose ID MM | 38.100 |
| Compatible hoses | EC110 |
| Construction Style | Crimp |
| Hex size 1 IN | 0.000 |
| Hex size 1 MM | 0.000 |
| Hex size 2 IN | 0.000 |
| Hose size | -24 |
| Inside diameter IN | 1.730 |
| Inside diameter MM | 44.000 |
| Product height in | 2.284 |
| Product height mm | 58.000 |
| Product length in | 2.913 |
| Product length mm | 74.000 |
| Product material | 304 Stainless steel |
| Product width in | 2.284 |
| Product width mm | 58.000 mm |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
