Product specifications
Characteristic | Value |
|---|---|
| A dimension MM | 69.500 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Construction Style | Reusable |
| End size 1 | -4 |
| End type 1 | Male pipe BSPT |
| End type 2 | Male barb |
| Hex size 1 IN | 0.669 |
| Hex size 1 MM | 16.993 |
| Hose cut off factor IN | 1.650 |
| Hose cut off factor MM | 42.000 |
| Hose size | -8 |
| Inside diameter IN | 0.350 |
| Inside diameter MM | 9.000 |
| Product height in | 6.690 |
| Product height mm | 17.000 |
| Product length in | 3.937 |
| Product length mm | 100.000 |
| Product material | Carbon steel |
| Product width in | 0.669 |
| Product width mm | 16.992 |
| Thread sealant | Yes |
| Thread size 1 | R 1/4 |
