Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.070 |
| A dimension MM | 103.500 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.800 |
| Construction Style | Crimp |
| End size 1 | -20 |
| End size 2 | -20 |
| End type 1 | Male pipe BSPT |
| End type 2 | Line/hose/tube |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.811 |
| Hex size 1 MM | 46.000 |
| Hose cut off factor IN | 1.940 |
| Hose cut off factor MM | 49.500 |
| Hose size | -20 |
| Inside diameter IN | 1.0600 |
| Inside diameter MM | 27.0000 |
| Product height in | 2.090 |
| Product height mm | 53.100 |
| Product length in | 4.074 |
| Product length mm | 103.500 |
| Product material | Carbon steel |
| Product width in | 1.811 |
| Product width mm | 46.000 mm |
| Series | Winner 2-Piece |
| Thread sealant | Yes |
| Thread size 1 | R 1 1/4 |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
