Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 5.980 |
| A dimension MM | 152.000 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 2.500 |
| Compatible hose ID MM | 63.500 |
| Construction Style | Crimp |
| End size 1 | -40 |
| End type 1 | Male pipe (NPT) |
| Finish plating | Zinc plating |
| Hex size 1 IN | 2.950 |
| Hex size 1 MM | 74.930 |
| Hose cut off factor IN | 2.750 |
| Hose cut off factor MM | 70.000 |
| Hose size | -40 |
| Inside diameter IN | 2.120 |
| Inside diameter MM | 54.000 |
| Product height in | 3.400 |
| Product height mm | 86.360 |
| Product length in | 5.980 |
| Product length mm | 151.892 |
| Product material | Carbon steel |
| Product width in | 2.950 |
| Product width mm | 74.93 |
| Series | Winner 2-Piece |
| Thread sealant | Yes |
| Thread size 1 | 2 1/2-8 NPTF |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
