Product specifications
Characteristic | Value |
|---|---|
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.630 |
| Compatible hose ID MM | 16.002 |
| Construction Style | Crimp |
| Drop dimension IN | 2.220 |
| Drop dimension MM | 56.4 |
| End size 1 | -6 |
| End type 1 | Female BSPP swivel |
| Hex size 1 IN | 1.063 |
| Hex size 1 MM | 27.0 |
| Hose cut off factor IN | 2.410 |
| Hose cut off factor MM | 61.214 |
| Hose size | -10 |
| Inside diameter IN | 0.5000 |
| Inside diameter MM | 12.7000 |
| Thread sealant | No |
| Thread size 1 | G 5/8 |
