Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.960 |
| A dimension MM | 75.200 |
| Angle shape | 45 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.620 |
| Compatible hose ID MM | 15.900 |
| Construction Style | Crimp |
| Drop dimension IN | 0.630 |
| Drop dimension MM | 16.0 |
| End connection torque | 57-62 lb-ft(77-85 Nm) |
| End size 1 | -10 |
| End type 1 | Female 37 degree swivel |
| ERP Product Class | WY8 |
| ERP Product Group | D31 |
| ERP Product Line | 81 |
| ERP Stat Number | 72307 |
| Finish plating | Protective oil |
| Hose cut off factor IN | 1.790 |
| Hose cut off factor MM | 45.400 |
| Hose size | -10 |
| Inside diameter IN | 0.460 |
| Inside diameter MM | 11.700 |
| Product height in | 2.310 |
| Product height mm | 58.674 |
| Product length in | 3.393 |
| Product length mm | 99.822 |
| Product material | Carbon steel |
| Product width in | 1.386 |
| Product width mm | 35.204 mm |
| Series | 1A/Z Series |
| Thread size 1 | 7/8-14 UNF |
| Working pressure max bar | 350 |
| Working pressure max psi | 5100 |
| Working temperature max C | 150 |
| Working temperature max F | 302 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
General specifications
Characteristic | Value |
|---|---|
| EAN | 678146125125 |
