Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.070 |
| A dimension MM | 77.900 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.620 |
| Compatible hose ID MM | 15.900 |
| Compatible hoses | 2781 |
| Construction Style | Crimp |
| Drop dimension IN | 3.870 |
| Drop dimension MM | 98.30 |
| End size 1 | -10 |
| End Type 1 | Male STC connector |
| Finish plating | Protective oil |
| Hex size 1 IN | 0.000 |
| Hex size 1 MM | 0.000 |
| Hose cut off factor IN | 1.910 |
| Hose cut off factor MM | 48.514 |
| Hose size | -10 |
| Inside diameter IN | 0.453 |
| Inside diameter MM | 11.500 |
| Product height in | 3.870 |
| Product height mm | 98.298 |
| Product length in | 3.070 |
| Product length mm | 77.978 |
| Product material | Carbon steel |
| Product width in | 0.910 |
| Product width mm | 23.114 |
| Seal material | Hydrogenated Nitrile (HNBR) |
| Series | 1S |
