Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.744 |
| A dimension MM | 44.300 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.250 |
| Compatible hose ID MM | 6.400 |
| Compatible hoses | 2781 |
| Construction Style | Crimp |
| End size 1 | -4 |
| End Type 1 | Female BSPP swivel |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 0.750 |
| Hex size 1 MM | 19.050 |
| Hex size 2 MM | 19.000 |
| Hose cut off factor IN | 0.921 |
| Hose cut off factor MM | 23.400 |
| Hose size | -4 |
| Inside diameter IN | 0.169 |
| Inside diameter MM | 4.300 |
| Product height in | 0.750 |
| Product height mm | 19.050 |
| Product length in | 1.740 |
| Product length mm | 44.196 |
| Product material | Carbon steel |
| Product width in | 0.750 |
| Product width mm | 19.050 |
| Series | 1S |
| Thread size 1 | G 1/4 |
