Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.161 |
| A dimension MM | 29.500 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Construction Style | Crimp |
| End size 1 | -8 |
| Finish plating | Dura-Kote |
| Hose size | -8 |
| Inside diameter IN | 0.803 |
| Inside diameter MM | 20.400 |
| Product height in | 1.150 |
| Product height mm | 29.210 |
| Product length in | 1.160 |
| Product length mm | 29.464 |
| Product material | Carbon steel |
| Product width in | 1.150 |
| Product width mm | 29.210 mm |
| Series | 1SB |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146133670 |
