Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.060 |
| A dimension MM | 153.800 |
| Angle shape | 45 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.800 |
| Construction Style | Crimp |
| Drop dimension IN | 1.540 |
| Drop dimension MM | 39.10 |
| End type 1 | 24 deg. DKO swivel light duty |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.968 |
| Hex size 1 MM | 49.987 |
| Hex size 2 IN | 1.968 |
| Hex size 2 MM | 49.987 |
| Hose cut off factor IN | 3.930 |
| Hose cut off factor MM | 99.800 |
| Hose size | -20 |
| Inside diameter IN | 1.0600 |
| Inside diameter MM | 27.0000 |
| Product height in | 3.770 |
| Product height mm | 95.758 |
| Product length in | 7.040 |
| Product length mm | 178.816 |
| Product material | Carbon steel |
| Product width in | 2.320 |
| Product width mm | 58.928 mm |
| Seal material | Nitrile (NBR) |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Thread size 1 | M45x2 |
| Tube OD 1 IN | 1.377 |
| Tube OD 1 MM | 35.000 |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
