Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.700 |
| A dimension MM | 94.000 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.500 |
| Compatible hose ID MM | 38.100 |
| Construction Style | Crimp |
| End connection torque | 158-167 lb-ft(216-227 Nm) |
| End type 1 | Female 37 degree swivel |
| Hex size 1 IN | 2.360 |
| Hex size 1 MM | 59.9 |
| Hose cut off factor IN | 1.023 |
| Hose cut off factor MM | 26.000 |
| Hose size | -24 |
| Inside diameter IN | 1.2590 |
| Inside diameter MM | 32.0000 |
| Product height in | 2.720 |
| Product height mm | 69.088 |
| Product length in | 3.700 |
| Product length mm | 93.980 |
| Product material | 304 Stainless steel |
| Product width in | 2.640 |
| Product width mm | 67.056 mm |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Thread size 1 | 1 7/8-12 UN |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
