Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.200 |
| A dimension MM | 56.000 |
| Angle shape | 90 Degree |
| Backup hex size IN | 1.063 |
| Backup hex size MM | 27.000 |
| Brand | Winner by Danfoss |
| Catalog Item | 26790K-10-10Z |
| Compatible hose ID IN | 0.620 |
| Compatible hose ID MM | 15.875 |
| Construction Style | Crimp |
| Drop dimension IN | 1 |
| Drop dimension MM | 26 |
| End connection hex size IN | 0.748 |
| End connection hex size MM | 18.999 |
| End size 1 | -10 |
| End size 2 | -6 |
| End type 1 | Female 37 degree swivel |
| End type 2 | Line/hose/tube |
| Finish plating | Zinc plating |
| Hose cut off factor IN | 0.650 |
| Hose cut off factor MM | 16.700 |
| Hose size | -10 |
| Inside diameter IN | 0.480 |
| Inside diameter MM | 12.300 |
| Product height in | 1.889 |
| Product height mm | 47.980 |
| Product length in | 3.393 |
| Product length mm | 86.182 |
| Product material | Carbon steel |
| Product width in | 1.060 |
| Product width mm | 26.924 |
