Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.640 |
| A dimension MM | 118.000 |
| Angle shape | 90 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| Drop dimension IN | 2.600 |
| Drop dimension MM | 66.12 |
| End size 1 | -16 |
| End Type 1 | Female 37 degree swivel |
| Hex size 1 IN | 1.614 |
| Hex size 1 MM | 41.000 |
| Hose cut off factor IN | 2.790 |
| Hose cut off factor MM | 71.000 |
| Hose size | -16 |
| Inside diameter IN | 0.830 |
| Inside diameter MM | 21.000 |
| Product height in | 3.820 |
| Product height mm | 97.050 |
| Product length in | 5.649 |
| Product length mm | 143.500 |
| Product material | 304 Stainless steel |
| Product width in | 1.614 |
| Product width mm | 41.000 |
| Thread size 1 | 1 5/16-12 UN |
