Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 7.590 |
| A dimension MM | 192.800 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 2.500 |
| Compatible hose ID MM | 63.500 |
| Compatible hoses | 2661 |
| Construction Style | Crimp |
| Drop dimension IN | 5.000 |
| Drop dimension MM | 132.00 |
| End size 1 | -40 |
| End type 1 | Flange Flat Face C61 |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 4.880 |
| Hose cut off factor MM | 123.952 |
| Hose size | -40 |
| Inside diameter IN | 2.090 |
| Inside diameter MM | 53.086 |
| Product material | Carbon steel |
