Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 0.687 |
| A dimension MM | 17.450 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| End size 1 | -20 |
| End type 1 | Female ORFS swivel |
| Finish plating | Protective oil |
| Hose size | -16 |
| Inside diameter IN | 1.004 |
| Inside diameter MM | 25.502 |
| Product material | Carbon steel |
| Series | FC Series |
| Thread sealant | No |
| Working pressure max BAR | 310 |
| Working pressure max PSI | 4500 |
