Product specifications

Characteristic
Value
A dimension IN3.050
A dimension MM77.500
Angle shape90 Degree
Compatible hose ID IN0.310
Compatible hose ID MM9.652
Compatible hoses1509
Construction StyleReusable
Drop dimension IN1.330
Drop dimension MM33.8
End size 1-6
End size 2-6
End type 124 deg. DKO swivel light duty
Finish platingZinc plating
Hex size 1 IN0.748
Hex size 1 MM19.0
Hex size 2 IN0.669
Hex size 2 MM17.0
Hose cut off factor IN1.610
Hose cut off factor MM41.000
Hose size-6
Inside diameter IN0.3100
Inside diameter MM7.9000
Product height in1.670
Product height mm42.418
Product length in3.430
Product length mm87.122
Product materialCarbon steel
Product width in0.750
Product width mm19.050 mm
Seal materialNitrile (NBR)
Thread sealantNo
Thread size 1M16x1.5
Working temperature max C121
Working temperature max F250
Working temperature min C-40
Working temperature min F-40
