Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.488 |
| A dimension MM | 114.000 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 3.000 |
| Compatible hose ID MM | 76.200 |
| Construction Style | Crimp |
| End size 1 | -48 |
| Hose cut off factor IN | 1.181 |
| Hose cut off factor MM | 30.000 |
| Hose size | -48 |
| Inside diameter IN | 2.500 |
| Inside diameter MM | 63.500 |
| Product height in | 4.490 |
| Product height mm | 114.046 |
| Product length in | 4.490 |
| Product length mm | 114.046 |
| Product material | Cupronickel |
| Product width in | 4.490 |
| Product width mm | 114.046 |
