Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.250 |
| A dimension MM | 57.150 |
| Angle shape | Straight |
| Brand | Winner Duffield by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Swage |
| End Type 1 | Female compression |
| End Type 2 | Line/hose/tube |
| Finish plating | Zinc plating |
| Hose size | -16 |
| Inside diameter IN | 1.267 |
| Inside diameter MM | 32.181 |
| Product height in | 1.866 |
| Product height mm | 47.396 |
| Product length in | 2.250 |
| Product length mm | 57.150 |
| Product material | Carbon steel |
| Product width in | 1.866 |
| Product width mm | 47.396 mm |
| Thread sealant | No |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min F | 40 |
