Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.080 |
| A dimension MM | 78.232 |
| Angle shape | Straight |
| Brand | Winner Duffield by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.750 |
| Construction Style | Swage |
| Finish plating | Zinc plating |
| Hose size | -20 |
| Inside diameter IN | 1.580 |
| Inside diameter MM | 40.132 |
| Product height in | 2.410 |
| Product height mm | 61.214 |
| Product length in | 3.030 |
| Product length mm | 76.962 |
| Product material | Carbon steel |
| Product width in | 2.410 |
| Product width mm | 61.214 mm |
| Thread sealant | No |
| Working temperature max C | 121 |
| Working temperature min C | 40 |
| Working temperature min F | 40 |
