Product specifications
Characteristic | Value |
|---|---|
| Abrasion resistance | Standard |
| Bend radius min (inch) | 2.560 |
| Bend radius min (mm) | 65.020 |
| Brand | Danfoss |
| Burst pressure (bar) | 40 |
| Burst pressure (psi) | 580 |
| Color | Black |
| Construction | 1 Ply braid |
| Cover material | EthyleneVinylAcetat(EVA Blend) |
| Impulse cycle (cycles) | 100000 |
| Inside diameter (inch) | 1.50 |
| Inside diameter (mm) | 38.10 |
| Lay line style | Ink transfer |
| Outside diameter (inch) | 2.06 |
| Outside diameter (mm) | 52.32 |
| Series | EC190 Series |
| Size | -24 |
| Tube material | Nitrile Blend (NBR Blend) |
| Tube wall thickness (inch) | 0.28 |
| Tube wall thickness (mm) | 7.11 |
| Vacuum rating (inHg) | 1 |
| Vacuum rating (mmHg) | 0.80 |
| Working pressure max (bar) | 10 |
| Working pressure max (psi) | 145 |
| Working temperature max (C) | 135 |
| Working temperature max (F) | 275.0 |
| Working temperature min (C) | -40 |
| Working temperature min (F) | -40.0 |
General specifications
Characteristic | Value |
|---|---|
| Proposition 65 | Cancer and Reproductive Harm |
