Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.450 |
| A dimension MM | 37.000 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.500 |
| Compatible hose ID MM | 12.700 |
| Construction Style | Crimp |
| Hose size | -8 |
| Inside diameter IN | 0.680 |
| Inside diameter MM | 17.500 |
| Product height in | 1.410 |
| Product height mm | 35.814 |
| Product length in | 1.460 |
| Product length mm | 37.084 |
| Product material | 316L Stainless steel |
| Product width in | 1.410 |
| Product width mm | 35.814 |
| Series | Winner 2-Piece |
| Thread sealant | No |
