Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.740 |
| A dimension MM | 171.200 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| Drop dimension IN | 0.220 |
| Drop dimension MM | 5.50 |
| End size 1 | -16 |
| End type 1 | Split flange code 62 |
| Finish plating | Protective oil |
| Hose cut off factor IN | 4.110 |
| Hose cut off factor MM | 104.500 |
| Hose size | -16 |
| Inside diameter IN | 0.770 |
| Inside diameter MM | 19.600 |
| Product height in | 2.102 |
| Product height mm | 53.401 |
| Product length in | 6.913 |
| Product length mm | 175.600 |
| Product material | Carbon steel |
| Product width in | 1.878 |
| Product width mm | 47.701 |
| Series | 1A/Z Series |
| Thread sealant | No |
| Working pressure max bar | 414 |
| Working pressure max psi | 6000 |
