Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.610 |
| A dimension MM | 167.800 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.800 |
| Construction Style | Crimp |
| Drop dimension IN | 5.120 |
| Drop dimension MM | 130.00 |
| End size 1 | -20 |
| End type 1 | Split flange code 62 |
| Finish plating | Protective oil |
| Hose cut off factor IN | 3.660 |
| Hose cut off factor MM | 92.900 |
| Hose size | -20 |
| Inside diameter IN | 1.000 |
| Inside diameter MM | 25.500 |
| Product height in | 6.122 |
| Product height mm | 155.501 |
| Product length in | 7.669 |
| Product length mm | 194.800 |
| Product material | Carbon steel |
| Product width in | 2.126 |
| Product width mm | 54.000 |
| Series | 1A/Z Series |
