Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 7.180 |
| A dimension MM | 182.300 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| Drop dimension IN | 2.670 |
| Drop dimension MM | 67.90 |
| End size 1 | -16 |
| End Type 1 | Split flange code 62 |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.000 |
| Hex size 1 MM | 0.000 |
| Hex size 2 IN | 0.000 |
| Hose cut off factor IN | 4.560 |
| Hose cut off factor MM | 115.700 |
| Hose size | -16 |
| Inside diameter IN | 0.770 |
| Inside diameter MM | 19.600 |
| Product height in | 3.690 |
| Product height mm | 93.726 |
| Product length in | 8.120 |
| Product length mm | 206.248 |
| Product material | Carbon steel |
| Product width in | 1.870 |
| Product width mm | 47.498 |
| SERIES | 1A/Z Series |
| Thread sealant | No |
| Working pressure max bar | 414.00 |
| Working pressure max psi | 6000.00 |
