Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.700 |
| A dimension MM | 119.300 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.750 |
| Compatible hose ID MM | 19.000 |
| Construction Style | Crimp |
| Drop dimension IN | 2.240 |
| Drop dimension MM | 57.00 |
| End size 1 | -12 |
| End Type 1 | Female BSPP swivel |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.260 |
| Hex size 1 MM | 32.000 |
| Hose cut off factor IN | 2.650 |
| Hose cut off factor MM | 67.300 |
| Hose size | -12 |
| Inside diameter IN | 0.590 |
| Inside diameter MM | 15.100 |
| Product height in | 2.541 |
| Product height mm | 64.550 |
| Product length in | 5.315 |
| Product length mm | 135.000 |
| Product material | Carbon steel |
| Product width in | 1.454 |
| Product width mm | 36.950 |
| Series | 1W |
| Thread size 1 | G 3/4 |
