Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 4.340 |
| A dimension MM | 110.400 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 0.750 |
| Compatible hose ID MM | 19.000 |
| Construction Style | Crimp |
| Drop dimension IN | 2.120 |
| Drop dimension MM | 54.00 |
| End connection torque | 108-113 lb-ft(148-154 Nm) |
| End size 1 | -16 |
| End Type 1 | 24 deg. DKO swivel heavy duty |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 1.417 |
| Hex size 1 MM | 36.000 |
| Hose cut off factor IN | 2.290 |
| Hose cut off factor MM | 58.400 |
| Hose size | -12 |
| Inside diameter IN | 0.590 |
| Inside diameter MM | 15.100 |
| Product height in | 2.423 |
| Product height mm | 61.550 |
| Product length in | 5.055 |
| Product length mm | 128.400 |
| Product material | Carbon steel |
| Product width in | 1.636 |
| Product width mm | 41.560 |
| Seal material | Nitrile (NBR) |
| Series | 1W |
| Thread size 1 | M30x2 |
| Tube OD 1 IN | 0.780 |
| Tube OD 1 MM | 20.000 |
