Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 7.780 |
| A dimension MM | 197.700 |
| Angle shape | 30 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| Drop dimension IN | 1.850 |
| Drop dimension MM | 47.00 |
| End connection torque | 43-48 lb-ft(59-64 Nm) |
| End size 1 | -16 |
| End type 1 | Split flange code 62 |
| End type 2 | Line/hose/tube |
| Finish plating | Zinc plating |
| Hose cut off factor IN | 5.160 |
| Hose cut off factor MM | 131.100 |
| Hose size | -16 |
| Inside diameter IN | 0.790 |
| Inside diameter MM | 20.000 |
| Product height in | 3.586 |
| Product height mm | 91.084 |
| Product length in | 8.720 |
| Product length mm | 221.488 |
| Product material | Carbon steel |
| Product width in | 1.874 |
| Product width mm | 47.599 |
| Series | 1W |
