Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.000 |
| A dimension MM | 149.600 |
| Angle shape | 90 Degree |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| Drop dimension IN | 2.800 |
| Drop dimension MM | 71.00 |
| End connection torque | 92-100 lb-ft(125-136 Nm) |
| End size 1 | -16 |
| End Type 1 | Female ORFS swivel |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.614 |
| Hex size 1 MM | 41.000 |
| Hose cut off factor IN | 3.270 |
| Hose cut off factor MM | 83.000 |
| Hose size | -16 |
| Inside diameter IN | 0.770 |
| Inside diameter MM | 19.600 |
| Product height in | 3.763 |
| Product height mm | 95.600 |
| Product length in | 6.696 |
| Product length mm | 170.100 |
| Product material | Carbon steel |
| Product width in | 1.863 |
| Product width mm | 47.340 |
| Series | 1W |
| Thread size 1 | 1 7/16-12 UN |
