Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 8.063 |
| A dimension MM | 204.800 |
| Angle shape | Straight |
| Brand | Aeroquip by Danfoss |
| Compatible hose ID IN | 2.500 |
| Compatible hose ID MM | 63.500 |
| Compatible hoses | FC325 GH213 GH466 GH466BGH506 GH506B GH810 |
| Construction Style | Crimp |
| End size 1 | -40 |
| End size 2 | -40 |
| End type 1 | Split flange code 62 |
| End type 2 | Line/hose/tube |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 3.370 |
| Hose cut off factor MM | 85.650 |
| Hose size | -40 |
| Inside diameter IN | 2.100 |
| Inside diameter MM | 53.600 |
| Product height in | 4.252 |
| Product height mm | 108.001 |
| Product length in | 8.063 |
| Product length mm | 204.800 |
| Product material | Carbon steel |
| Product width in | 4.252 |
| Product width mm | 108.001 |
