Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.930 |
| A dimension MM | 74.500 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.750 |
| Compatible hose ID MM | 19.000 |
| Construction Style | Crimp |
| End size 1 | -24 |
| End type 1 | 24 deg. DKO swivel heavy duty |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.180 |
| Hex size 1 MM | 29.972 |
| Hose cut off factor IN | 1.130 |
| Hose cut off factor MM | 28.800 |
| Hose size | -12 |
| Inside diameter IN | 0.2750 |
| Inside diameter MM | 15.0000 |
| Product height in | 1.360 |
| Product height mm | 34.544 |
| Product length in | 2.930 |
| Product length mm | 74.422 |
| Product material | Carbon steel |
| Product width in | 1.181 |
| Product width mm | 29.972 mm |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Working pressure max bar | 172 |
| Working pressure max psi | 2500 |
