Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.464 |
| A dimension MM | 88.000 |
| Angle shape | Straight |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 0.750 |
| Compatible hose ID MM | 19.000 |
| Construction Style | Crimp |
| End type 1 | 24 deg. DKO swivel heavy duty |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.000 |
| Hex size 1 MM | 40.894 |
| Hose cut off factor IN | 1.515 |
| Hose cut off factor MM | 38.500 |
| Hose size | -12 |
| Inside diameter IN | 0.562 |
| Inside diameter MM | 14.300 |
| Product height in | 1.810 |
| Product height mm | 45.974 |
| Product length in | 3.460 |
| Product length mm | 87.884 |
| Product material | Carbon steel |
| Product width in | 1.610 |
| Product width mm | 40.894 mm |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
