Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 5.688 |
| A dimension MM | 144.500 |
| Angle shape | 90 Degree |
| Brand | Winner by Danfoss |
| Catalog Item | 20593-42-16WZ |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| Drop dimension IN | 2.755 |
| Drop dimension MM | 70.00 |
| End type 1 | 24 deg. DKO swivel heavy duty |
| Finish plating | Zinc plating |
| Hex size 1 IN | 1.960 |
| Hex size 1 MM | 49.784 |
| Hose cut off factor IN | 3.224 |
| Hose cut off factor MM | 81.900 |
| Hose size | -16 |
| Inside diameter IN | 0.748 |
| Inside diameter MM | 19.000 |
| Product height in | 3.484 |
| Product height mm | 88.493 |
| Product length in | 6.447 |
| Product length mm | 163.754 |
| Product material | Carbon steel |
| Product width in | 1.960 |
| Product width mm | 49.784 |
| Series | Winner 2-Piece |
| Thread size 1 | M42x2 |
| Tube OD 1 IN | 1.181 |
| Tube OD 1 MM | 30.000 |
