Product specifications
Characteristic | Value |
---|---|
A dimension MM | 58.700 |
Angle shape | Straight |
Brand | Winner by Danfoss |
Compatible hose ID IN | 1.500 |
Compatible hose ID MM | 38.100 |
Compatible hoses | GH4932755GH506 |
Construction Style | Crimp |
End size 1 | -24 |
End type 1 | Female BSPP swivel |
Hex size 2 IN | 2.170 |
Hex size 2 MM | 55.118 |
Hose cut off factor IN | 0.000 |
Hose size | -24 |
Inside diameter IN | 2.322 |
Inside diameter MM | 59.000 |
Product height in | 5.590 |
Product height mm | 141.986 |
Product length in | 8.220 |
Product length mm | 208.788 |
Product material | Carbon steel |
Product width in | 2.170 |
Product width mm | 55.118 mm |
Thread sealant | No |
Thread size 1 | G 1 1/2 |
