Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.732 |
| A dimension MM | 94.800 |
| Angle shape | 90 Degree |
| Brand | Winner by Danfoss |
| Compatible hose ID IN | 1.500 |
| Compatible hose ID MM | 38.100 |
| Construction Style | Crimp |
| Drop dimension IN | 4.055 |
| Drop dimension MM | 103.00 |
| End size 1 | -24 |
| End Type 1 | Female BSPP swivel |
| Finish plating | Zinc plating |
| Hex size 1 IN | 2.165 |
| Hex size 1 MM | 55.000 |
| Hex size 2 IN | 2.170 |
| Hex size 2 MM | 55.118 |
| Hose cut off factor IN | 4.889 |
| Hose cut off factor MM | 124.200 |
| Hose size | -24 |
| Inside diameter IN | 1.200 |
| Inside diameter MM | 30.500 |
| Product height in | 5.550 |
| Product height mm | 140.970 |
| Product length in | 9.700 |
| Product length mm | 246.380 |
| Product material | Carbon steel |
| Product width in | 2.170 |
| Product width mm | 55.118 |
| Thread size 1 | G 1 1/2 |
