Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 5.590 |
| A dimension MM | 141.900 |
| Angle shape | Straight |
| Brand | Danfoss |
| Compatible hose ID IN | 2.000 |
| Compatible hose ID MM | 50.800 |
| Construction Style | Crimp |
| End Type 1 | Female BSPP swivel |
| End size 1 | -32 |
| Finish plating | Zinc plating |
| Hex size 1 IN | 2.755 |
| Hex size 1 MM | 70.000 |
| Hose cut off factor IN | 1.320 |
| Hose cut off factor MM | 33.500 |
| Hose size | -32 |
| Inside diameter IN | 1.660 |
| Inside diameter MM | 42.100 |
| Product material | Carbon steel |
| Thread sealant | No |
| Thread size 1 | G 2 |
| Working pressure max bar | 110 |
| Working pressure max psi | 1600 |
| Working temperature max C | 100 |
| Working temperature max F | 212 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
