Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 3.530 |
| A dimension MM | 89.800 |
| Angle shape | Straight |
| Brand | Danfoss |
| Compatible hose ID IN | 1.000 |
| Construction Style | Crimp |
| End size 1 | -16 |
| End type 1 | Male BSPP 60 degree cone |
| Finish plating | Dura-Kote |
| Hex size 2 IN | 1.625 |
| Hex size 2 MM | 41.000 |
| Hose cut off factor IN | 1.970 |
| Hose cut off factor MM | 50.100 |
| Inside diameter IN | 0.750 |
| Inside diameter MM | 19.200 |
| Product height in | 2.084 |
| Product height mm | 52.933 |
| Product length in | 3.650 |
| Product length mm | 92.710 |
| Product material | Carbon steel |
| Product width in | 2.084 |
| Product width mm | 52.933 |
| Thread sealant | No |
| Thread size 1 | G 1 |
| Working pressure max bar | 280 |
| Working pressure max psi | 4050 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146153579 |
