Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.870 |
| A dimension MM | 72.900 |
| Angle shape | Straight |
| Brand | Danfoss |
| Compatible hose ID IN | 0.750 |
| Construction Style | Crimp |
| End size 1 | -20 |
| End type 1 | 24 deg. tube port light duty |
| Finish plating | Dura-Kote |
| Hex size 1 IN | 1.250 |
| Hex size 1 MM | 32.000 |
| Hose cut off factor IN | 1.440 |
| Hose cut off factor MM | 36.600 |
| Inside diameter IN | 0.560 |
| Inside diameter MM | 14.200 |
| Product height in | 1.836 |
| Product height mm | 46.640 |
| Product length in | 2.870 |
| Product length mm | 72.900 |
| Product material | Carbon steel |
| Product width in | 1.836 |
| Product width mm | 46.64 |
| Thread sealant | No |
| Thread size 1 | M30x2 |
| Working pressure max bar | 100 |
| Working pressure max psi | 1450 |
| Working temperature max C | 127 |
| Working temperature max F | 260 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
