Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.063 |
| A dimension MM | 52.400 |
| Angle shape | Straight |
| Compatible hose ID IN | 1.000 |
| Compatible hose ID MM | 25.400 |
| Construction Style | Crimp |
| End size 1 | -16 |
| Finish plating | Dura-Kote |
| Hose size | -16 |
| Inside diameter IN | 1.093 |
| Inside diameter MM | 27.750 |
| Product height in | 2.340 |
| Product height mm | 59.436 |
| Product length in | 2.060 |
| Product length mm | 52.324 |
| Product material | Carbon steel |
| Product width in | 2.340 |
| Product width mm | 59.436 mm |
| Thread sealant | No |
| Working temperature max C | 127 |
| Working temperature max F | 260 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
