Product specifications
Characteristic | Value |
|---|---|
| Angle shape | 60 Degree |
| Brand | Danfoss |
| Compatible hose ID IN | 2.000 |
| Compatible hose ID MM | 50.800 |
| Compatible hoses | FC500 (Size dependent) |
| Compatible tube OD IN | 2.00 |
| Compatible tube OD MM | 50.800 |
| Compliances | SAE J1176 |
| Construction Style | Crimp |
| Drop dimension IN | 3.440 |
| Drop dimension MM | 87.4 |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 9.130 |
| Hose cut off factor MM | 231.902 |
| Hose size | -32 |
| Inside diameter IN | 1.6600 |
| Inside diameter MM | 42.1640 |
| Product material | Carbon steel |
| Thread sealant | No |
| Tube OD 1 IN | 2.000 |
| Tube OD 1 MM | 50.800 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 815628023160 |
