Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 6.330 |
| A dimension MM | 160.800 |
| Angle shape | Straight |
| Compatible hose ID IN | 2.000 |
| Compatible hose ID MM | 50.800 |
| Construction Style | Crimp |
| End size 1 | -32 |
| End type 1 | Male API std. 5B line pipe |
| Finish plating | Dura-Kote |
| Hex size 2 IN | 2.500 |
| Hex size 2 MM | 64.000 |
| Hose cut off factor IN | 3.260 |
| Hose cut off factor MM | 82.800 |
| Hose size | -32 |
| Inside diameter IN | 1.660 |
| Inside diameter MM | 42.100 |
| Product material | Carbon steel |
| Seal material | Ethylene Propylene (EPDM) |
| Series | 1Z |
| Working temperature max C | 121 |
| Working temperature max F | 250 |
| Working temperature min C | -40 |
| Working temperature min F | -40 |
