Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 7.787 |
| A dimension MM | 197.800 |
| Angle shape | 45 Degree |
| Brand | Winner by Danfoss |
| Catalog Item | 43020E-B00E80-U |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.800 |
| Construction Style | Crimp |
| Drop dimension IN | 1.633 |
| Drop dimension MM | 41.48 |
| End size 1 | -20 |
| End type 1 | Split flange code 62 |
| Finish plating | Zinc plating |
| Hose cut off factor IN | 4.590 |
| Hose cut off factor MM | 116.586 |
| Hose size | -20 |
| Inside diameter IN | 0.944 |
| Inside diameter MM | 23.978 |
| Product material | Carbon steel |
| Series | Winner 2-Piece |
| Thread sealant | No |
| Working pressure max PSI | 6000 |
