Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 8.190 |
| A dimension MM | 208.000 |
| Brand | Aeroquip by Danfoss |
| Catalog Item | GL25138-2420.140 |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.750 |
| Construction Style | Crimp |
| Drop dimension IN | 5.550 |
| Drop dimension MM | 141.00 |
| End size 1 | -24 |
| End type 1 | Split flange code 62 |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 5.270 |
| Hose cut off factor MM | 133.900 |
| Hose size | -20 |
| Inside diameter IN | 1.000 |
| Inside diameter MM | 25.500 |
| Product height in | 6.970 |
| Product height mm | 177.038 |
| Product length in | 9.740 |
| Product length mm | 247.396 |
| Product material | Carbon steel |
| Product width in | 3.750 |
| Product width mm | 95.250 |
| Seal material | Ethylene Propylene (EPDM) |
