Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 9.020 |
| A dimension MM | 229.000 |
| Angle shape | 15 Degree |
| Brand | Aeroquip by Danfoss |
| Catalog Item | GL25140-2020.020 |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.750 |
| Construction Style | Crimp |
| Drop dimension IN | 0.790 |
| Drop dimension MM | 20.00 |
| End size 1 | -20 |
| End type 1 | Split flange code 62 |
| End type 2 | Line/hose/tube |
| Finish plating | Dura-Kote |
| Hose cut off factor IN | 6.080 |
| Hose cut off factor MM | 154.400 |
| Hose size | -20 |
| Inside diameter IN | 1.000 |
| Inside diameter MM | 25.500 |
| Product height in | 3.920 |
| Product height mm | 99.568 |
| Product length in | 10.140 |
| Product length mm | 257.556 |
| Product material | Carbon steel |
| Product width in | 3.803 |
| Product width mm | 96.596 |
| Seal material | Ethylene Propylene (EPDM) |
