Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 7.200 |
| A dimension MM | 183.000 |
| Angle shape | 120 Degree |
| Catalog Item | GL25211-2424.185 |
| Compatible hose ID IN | 1.500 |
| Compatible hose ID MM | 38.100 |
| Construction Style | Crimp |
| Drop dimension IN | 7.280 |
| Drop dimension MM | 185.00 |
| End size 1 | -24 |
| End type 1 | Split flange code 62 |
| Finish plating | Zinc plating |
| Hose cut off factor IN | 3.280 |
| Hose cut off factor MM | 83.400 |
| Hose size | -24 |
| Inside diameter IN | 1.180 |
| Inside diameter MM | 30.000 |
| Product height in | 8.673 |
| Product height mm | 220.299 |
| Product length in | 9.961 |
| Product length mm | 252.999 |
| Product material | Carbon steel |
| Product width in | 4.461 |
| Product width mm | 113.299 |
| Seal material | Ethylene Propylene (EPDM) |
