Product specifications
Characteristic | Value |
|---|---|
| Abrasion resistance | Premium |
| Bend radius min (inch) | 1.250 |
| Bend radius min (mm) | 31.750 |
| Brand | Synflex by Danfoss |
| Burst pressure (bar) | 414 |
| Burst pressure (psi) | 6000 |
| Catalog Item | 3R30-04006 |
| Certifications | SAE 100R3 |
| Color | Black |
| Conditional temp range | -40F to 150F fire resistant-40F to 150F for water based |
| Cover material | Polyurethane (TPU) |
| Inside diameter (inch) | 0.19 |
| Inside diameter (mm) | 4.83 |
| Outside diameter (inch) | 0.38 |
| Outside diameter (mm) | 9.65 |
| Qualified hose fittings | 90390A |
| Reinforcement material | Fiberglass |
| Size | -4 |
| Tube material | Nylon lined |
| Working pressure max (bar) | 103 |
| Working pressure max (psi) | 1500 |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 639789365019 |
