Product specifications
Characteristic | Value |
|---|---|
| Abrasion resistance | Premium |
| Bend radius min (inch) | 40.000 |
| Bend radius min (mm) | 88.900 |
| Brand | Synflex by Danfoss |
| Burst pressure (bar) | 79 |
| Burst pressure (psi) | 1148 |
| Certifications | SAE 100R18 |
| Color | Black |
| Conditional temp range | -54C to 66C fire resistant-54C to 66C for water based-54C to 94C for petrol based-54C to 94C for synthetic |
| Construction | 2 Ply braid |
| Cover material | Polyurethane (TPU) |
| Impulse cycle (cycles) | 200000 |
| Inside diameter (inch) | 0.51 |
| Inside diameter (mm) | 12.90 |
| Lay line style | Ink jet |
| Outside diameter (inch) | 0.84 |
| Outside diameter (mm) | 21.34 |
| Reinforcement material | Brass plated steel wireFiber |
| Series | 3TB0 Series |
| Size | -8 |
| Tech. Char for It.MDS MM & APO | X |
| Tube material | Polyester (PEE) |
| Working pressure max (bar) | 20 |
| Working pressure max (psi) | 287 |
| Working temperature min (C) | -48 |
| Working temperature min (F) | -54.0 |
