Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.410 |
| A dimension MM | 35.800 |
| Angle shape | 90 Degree |
| Brand | Aeroquip Performance Danfoss |
| Construction Style | Reusable |
| Drop dimension IN | 0.680 |
| Drop dimension MM | 17.30 |
| End type 1 | Female 37 degree swivel |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.551 |
| Hex size 1 MM | 14.000 |
| Hex size 2 IN | 0.551 |
| Hex size 2 MM | 14.000 |
| Hose cut off factor IN | 0.460 |
| Hose cut off factor MM | 11.700 |
| Inside diameter IN | 0.160 |
| Inside diameter MM | 4.100 |
| Product height in | 1.360 |
| Product height mm | 34.544 |
| Product length in | 1.690 |
| Product length mm | 42.926 |
| Product material | Carbon steel |
| Product width in | 0.562 |
| Product width mm | 14.287 |
| Thread size 1 | 7/16-20 UNF |
General specifications
Characteristic | Value |
|---|---|
| EAN/UPC | 678146088932 |
