Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 2.362 |
| A dimension MM | 59.994 |
| Angle shape | Straight |
| Compatible hose ID IN | 0.620 |
| Compatible hose ID MM | 15.875 |
| Compatible hoses | FC173 |
| Construction Style | Reusable |
| End size 1 | -10 |
| End size 2 | -6 |
| End Type 1 | Female 37 degree swivel |
| End Type 2 | Line/hose/tube |
| Finish plating | Zinc plating |
| Hex size 1 IN | 0.984 |
| Hex size 1 MM | 25.000 |
| Hex size 2 IN | 0.984 |
| Hex size 2 MM | 25.000 |
| Hose cut off factor IN | 1.391 |
| Hose cut off factor MM | 35.348 |
| Hose size | -10 |
| Inside diameter IN | 0.420 |
| Inside diameter MM | 10.668 |
| Matr grp for sales restriction | Country Excluded Products |
| Product height in | 1.150 |
| Product height mm | 29.210 |
| Product length in | 2.620 |
| Product length mm | 66.548 |
| Product material | Carbon steel |
| Product width in | 1.000 |
| Product width mm | 25.400 mm |
| Thread sealant | No |
| Thread size 1 | 7/8-14 UNF |
