Product specifications
Characteristic | Value |
|---|---|
| A dimension IN | 1.147 |
| A dimension MM | 29.130 |
| Angle shape | Straight |
| Brand | Synflex by Danfoss |
| Catalog Item | 5980-20800 |
| Compatible hose ID IN | 1.250 |
| Compatible hose ID MM | 31.750 |
| End size 1 | -20 |
| End type 1 | Braze Type |
| Finish plating | Protective oil |
| Hose cut off factor IN | 0.296 |
| Hose cut off factor MM | 7.530 |
| Hose size | -20 |
| Inside diameter IN | 7.600 |
| Inside diameter MM | 1.930 |
| Product material | Carbon steel |
| Series | Thermoplastic Crimp |
| Thread sealant | No |
